14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance

200
MOQ
$1
preço
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Material: 14m 500 Dan Transmissão de eletricidade Aço
Altura de montagem: 14m
Forma: Redondo cônico; Octogonal cônico; Quadrado reto; Tubular pisado; Poligonal
Parênteses: Suportes únicos ou duplos conforme a necessidade do cliente
Padrão de solda: AWS D 1,1
Placa de base: Quadrado ou redondo com orifícios com fenda
Comprimento montado no solo: Conforme exigência do cliente
Espessura da galvanização: 80-100 µm Média
Revestimento em pó: Pintura de poliéster puro
Resistência ao vento: 3 a 500 km/h
Faixa de espessura: 1 mm a 30 mm
Construção do eixo: Folha de aço dobrada e longitudinalmente soldada
Processo de solda: Soldagem dupla interna e externa
Padrão da galvanização: IS2629-1985, BS729-1971
Peso de embalagem: 26T
Destacar:

14m Height Transmission Steel Pole

,

ISO9001/BV/SGS Certified Electric Power Pole

,

Wind Resistance 3-500km/h Steel Utility Pole

Informação básica
Lugar de origem: Jiangsu, China
Marca: Milky Way
Número do modelo: Energia elétrica ple
Condições de Pagamento e Envio
Descrição de produto
Galvanized Steel Electric Pole Transmission Monopole
Product Specifications
Material 14M 500 Dan Electricity Transmission Steel Utility Pole for Power Distribution Line Project
Mounting Height 14m
Shape of Pole Round conical; Octagonal conical; Straight square; Tubular stepped; Polygonal
Brackets Single or double brackets available in custom shapes and dimensions
Welding Complies with international welding standard CWB and AWS D1.1
Base Plate Square or round with slotted holes for anchor bolts (custom dimensions available)
Ground Mounting Buried length customized per requirements
Galvanizing Hot dip galvanization (80-100µm average thickness)
Powder Coating Pure polyester powder painting (color optional)
Wind Resistance 3-500 km/h
Thickness 1 mm to 30 mm
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 0
Production Process
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 1
Raw Material Processing

All raw materials (steel plates) include mill certificates and undergo elongation tests and chemical composition analysis before production to ensure compliance with required standards.

Cutting Process

Materials are precision-cut using CNC laser cutting technology, which delivers high-quality surface finishes through controlled melting and vaporization of material.

14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 2 14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 3
Molding & Welding

Steel plates are formed into specified shapes (circular, polygonal, etc.) using advanced bending machines. Longitudinal welding is performed with AC inverter control for stable, high-quality seams.

14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 4 14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 5
Galvanization

All poles receive hot-dip galvanization (IS2629-1985, BS729-1971 standards) for superior corrosion resistance.

Certifications
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 6
Company Profile
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 7

Established in 1991, Jiangsu Milky Way Steel Poles Co., Ltd. is located in Wuxi, China, near Shanghai Port. Our products serve power transmission, signal transmission, and lighting applications worldwide.

With over 20 years of manufacturing experience, we've exported to more than 70 countries and maintain BV, ISO, and SGS certifications.

Packing & Delivery
14m Height Hot Dip Galvanized Transmission Steel Pole with ISO9001/BV/SGS Certification and 3-500km/h Wind Resistance 8
Packing Size 40HQ
Weight 26T
Packaging Details Poles are packed with sea/road-worthy wooden materials. Loading capacity per container varies based on specifications.
Frequently Asked Questions
How can I get a price for a needed pole?

Provide exact dimensions (height, thickness, material, diameters) or send a drawing for accurate pricing.

Do you accept small orders?

Yes, we welcome small wholesalers and are happy to grow with our customers.

Can you produce custom-designed samples?

We specialize in helping customers realize their designs and solve technical challenges.

How does your Door to Door service work?

We handle all shipping and customs clearance, offering time and cost savings through our shipping partnerships.
